FIREBALL-623

FIREBALL-623

  • 6.5 “(16.6 CM) 3-WAY COAXIAL SPEAKER
  • Upgrade your vehicle’s audio system with the Aura Fireball-623, a high-performance 3-way coaxial car speaker designed to deliver outstanding sound quality and clarity. Engineered for precision and durability, this speaker is perfect for enhancing your driving experience with immersive audio. Read More

Key Specifications:

  • Diameter: 6.5" (165mm)

A compact size ideal for fitting in various car audio setups without compromising on sound performance.

  • Type: 3-Way Coaxial

Features a multi-driver design that provides a full range of sound with crisp highs, robust mids, and powerful lows.

  • Nominal Impedance: 4 Ohms

Compatible with most car amplifiers for versatile installation.

  • Frequency Response: 52Hz - 20kHz

Wide range ensures that you hear every detail of your music clearly.

  • Voice Coil Diameter: 1.0" (25.4mm)

Enhances power handling and improves thermal management for consistent performance.

  • Nominal Power: 45W RMS

Reliable power handling for everyday listening.

  • Maximum Power: 300W

Handles peak power for dynamic and high-impact audio.

  • Free Air Resonance: 69Hz

Delivers strong, clean bass response with minimal distortion.

  • QTS: 0.74
  • <

Offers a balanced performance with extended low-frequency response and efficiency.

  • VAS: 0.47ft³ (13.3L)

Ensures optimal alignment and acoustic accuracy.

  • Sensitivity: 90dB

High efficiency provides strong sound output with minimal power requirements.

  • Xmax: 0.07"

Accurate cone movement for clearer, more precise audio reproduction.

  • Mounting Diameter: 5.51"

Standard size for straightforward installation in most car audio setups.

  • Mounting Depth: 2.15"

Slim profile allows for easy fitting in tight spaces.

Enhance your car audio system with the Aura Fireball-623 and enjoy superior sound quality on the go. Designed to fit a wide range of vehicles and audio systems, this speaker is your ticket to a richer, more immersive listening experience.

Image 1
Image 2
Model FIREBALL-623 Qts 0.74
Nominal Diameter 6.5'(165mm) Vas 0.47ft3(13.3L)
Discription 3-way-Coaxial Senstivity(1W/1M) 90dB
Nominal Impendence 4Ohm Xmax 0.07'(1.9mm)
Frequency Response 52-20kHz Mounting Diameter 5.51'(140mm)
Voice Coil Diameter 1.0'(25.4mm) Mounting Depth 2.15'(54.5mm)
Power Rating(RMS/Peak) 45W/300W Grill/Trim Ring Yes
Fs- Free Air Resonance 69 Hz Adaptor Plate No
Name
Download
FIREBALL-623 INSTRUCTION MANUAL
